Gas Heat Pump

  • 80,000 btu/hr heating capacity
  • 140% AFUE lowers heating bills and CO2 emissions by up to 50%
  • Comfortable space heating down to -40° ambient for even the toughest winter
  • Quiet operation from a variable speed evaporator fan, modulated burner & no compressor motor
  • Environmentally friendly ultra-low NOx gas burner with 4:1 modulation for efficiency
  • 115V, less than 6 amp power means no expensive panel upgrades
  • Easy to power with a portable generator during power outages
  • Rear water and gas connections with built in isolation valves for easy, flexible installation
  • Steel base with built-in fork pockets for easy transport & installation
  • ANSI Z21.40.1- CGA 2.91 safety compliant

Specifications

Technical DataUnitValue
Heating Capacity*BTU/h78,000
COP (Higher Heating Value)*1.43
Max Return Temp (at full fire)° F/C132/55.6
Max Return Temp (at min fire)° F/C142/61.1
Delta T (at full fire)° F/C20/6.7
Gas Input (Higher Heating Value)BTU/h54,500
Modulation (fully variable)4:1
CombustionCondensing
NOx Compliance (Ultra-Low NOx)ng/J<14
Nominal Hydronic Flowgpm/lpm8.5/30
Glycol Concentration40%
Ambient Temp (min—max)° F/C-40 — 130/-40 — 54
VoltageVAC115
Maximum PowerAmp6
Lengthin/cm48/121.9
Widthin/cm34/86.4
Height || Height with Chimneyin/cm44/111.8 || 56.5/143.5
Weightlbs/kg550/249.5
Hydronic Connection FNPT – diain/cm1/2.5
Gas Connections FNPT – diain/cm0.5/1.3
Electrical Knockouts (x2) – diain/cm0.5/1.3
Hydronic Pressure Drop (Nominal Condition)psi/kPa5/34.5
Approximate NH3 Chargelbs/kg12/5.4
Approximate H2O Chargelbs/kg8/3.6
CTA2045 ComplianceFuture release
Communications CapabilitiesMODBUS
CertificationANSI, CGA
